*Secure locking device prevents accidental disconnection. *Header wafer is made of solder crack preventive material, glass-filled PA66 nylon. *Header pins are round and reflow-treated, which provides low insertion force. *Shrouded headers on radial-tape are also available. *Headers with polarizing bosses are also available.
Product Profile
Series
XA connector (W to B)
Category
Wire to Board Crimp style Connectors
Type
Disconnectable type Crimp style, With secure locking device
Feature
With secure locking device
Specification
Pitch
2.5 mm
Current rating
3A (AWG#22,#20)
Voltage rating
250V
PC board mounting direction
Top entry, Side entry
Compliant with RoHS. (LF)(SN) as identification part number shall be displayed on a label. When ordering RoHS compliant products, please inquire to the nearest JST Sales Office, or order them with the described part number adding (LF)(SN) as the identification marking after it.
