| 加工定制 | 否 |
|---|---|
| 材质 | 塑料 |
| 规格 | Jacob喇叭口防爆尼龙电缆接头 |
| 连接型式 | Jacob喇叭口防爆尼龙电缆接头 |
| 适用范围 | Jacob喇叭口防爆尼龙电缆接头 |
| 品牌 | Jacob喇叭口防爆尼龙电缆接头 |
| 型号 | Jacob喇叭口防爆尼龙电缆防水接头 |
EPIN-Jacob喇叭口防爆尼龙电缆防水接头（Jacob-Trumpet-shaped Ex-cable gland）
Jacob Trumpet-shaped Ex-cable gland 73xx B
>> Configuration
Pressure screw: Polyamide PAStrain relief clamp: Polyamide PABolt / Nut: Stainless steelSealing ring: Nitrile rubber NBR, multiple perforationGland body: Polyamide PAHexagonal locknut: Polyamide PA6Thread sealing ring: KLINGERsilConnecting thread: metric, as per EN 60423>> Propertiesexcellent anchoragewide clamping rangeEquipment group: IICategory / Zone: 2G, 2D and 3G/ 1, 2, 21, 22Type of protection: Ex e, increased safety, Ex tD A21 - Protection by enclosuresCable installation: flexibleTemperature range: -40°C/+85°CProtection grade: IP66
Test standard: EN 60079-0 / EN 60079-7, EN 61241-0 / EN 61241-1EC-Type certificate: PTB 00 ATEX 3121IECEx certificate: IECEx BKI 08.0007
>> Features
Connecting thread standard length
| mm | mm | mm | mm | mm | Piece | ||
| M20x1,5 | 8 - 13 | 15 | 27 | 77 | 40 | 10 | 7320 B |
| M25x1,5 | 11 - 16 | 15 | 32 | 80 | 43 | 10 | 7325 B |
| M32x1,5 | 15 - 20 | 15 | 41 | 92 | 54 | 10 | 7332 B |
| M40x1,5 | 19 - 27 | 15 | 50 | 98 | 64 | 10 | 7340 B |
| M50x1,5 | 26 - 34 | 16 | 60 | 108 | 73 | 1 | 7350 B |
| M63x1,5 | 35 - 46 | 16 | 75 | 119 | 89 | 1 | 7363 B |
